Reference Standard	GB/T 17702, IEC 61071
Climatic Category	40/85/56
Operating Temperature	-40～85℃（Θhs ≤ 85℃）
Storage Temperature	-40～85℃
Voltage Range	600Vdc～1500Vdc
Capacitance Range	35μF ~600μF
Capacitance Tolerance	±5%; ±10%
Test Voltage Between T-T	1.5Un (10s,20±5℃)
Test Voltage Between T-C	3Kvac (60s, 50Hz, 20±5℃)
tgδ	0.0002
IR×Cn	≥5,000s (20℃, 100Vdc, 1min)
Over voltage	1.1Un (30% of on-load-duration)
	1.15Un (30min/day)
	1.2Un (5min/day)
	1.3Un (1min/day)
	1.5Un (30ms per time, 1000 times during lifetime)
Max.Altitude during operation	2000m
Max.Torque of terminals	M5: 2.5Nm; M8:6Nm
Max. torque of installation	3Nm
Installation	Any direction
Failure rate	50 FIT

Reference Standard	IEC 61071
Climatic Category	40/1085/56
Operating Temperature	-40～105℃（Θhs ≤ 105℃） Θhs = 85℃~105℃: decreasing factor 1.5% per ℃ for Undc
Operating Temperature
Storage Temperature	-40～105℃
Voltage Range	450Vdc～900Vdc
Capacitance Range	47μF ~600μF
Capacitance Tolerance	±5%; ±10%
Test Voltage Between T-T	1.5Un (10s,20±5℃)
Test Voltage Between T-C	3Kvac (60s, 50Hz, 20±5℃)
tgδ	0.0002
IR×Cn	5,000s (20℃, 100Vdc, 1min)
Over voltage	1.1Un (30% of on-load-duration)
	1.15Un (30min/day)
	1.2Un (5min/day)
	1.3Un (1min/day)
	1.5Un (30ms per time, 1000 times during lifetime)
Max.Altitude during operation	2000m
Max.Torque of terminals	M5: 2.5Nm; M8:6Nm
Max. torque of installation	3Nm
Installation	Any direction
Failure rate	50 FIT

Un(Vdc)	Cn(μF)	ESR(mΩ)	L(nH)	Rth(K/W)	I(A)	Imax(A)-55℃	Imax(A)-60℃	Dimension φD	Dimension H	Average Weight(kg)
600	170	0.8	25	6.8	2051	74	60	84.5	41	0.35
	260	0.9	32	5.3	2193	79	64	84.5	50	0.4
	380	1	40	5	2135	77	63	84.5	65	0.48
	380	1	40	5.2	2135	76	62	83.2	65	0.47
	600	1.1	40	3.4	3791	89	73	115	64	0.9
800	100	0.9	25	6.8	2074	70	57	84.5	41	0.35
	150	1	32	5.3	2174	75	61	84.5	50	0.4
	220	1.1	40	5	2123	73	60	84.5	65	0.48
	220	1.1	40	5.2	2123	72	59	83.2	65	0.47
	350	1.3	40	3.4	3798	82	67	115	64	0.9
900	100	0.9	25	6.8	2074	70	57	84.5	41	0.35
	150	1	32	5.3	2174	75	61	84.5	50	0.4
	220	1.1	40	5	2123	73	60	84.5	65	0.48
	220	1.1	40	5.3	2123	72	59	83.2	65	0.47
	350	1.3	40	3.4	3798	82	67	115	64	0.9
1100	66	1.2	25	6.8	1828	60	49	84.5	41	0.35
	100	1.3	32	5.3	1936	66	53	84.5	50	0.4
	140	1.5	40	5	1805	63	51	84.5	65	0.48
	140	1.5	40	5.2	1805	62	50	83.2	65	0.47
	190	1.7	45	4.6	2003	61	50	84.5	76	0.55
	150	1.5	45	4.6	1861	65	53	84.5	76	0.55
	230	1.4	40	3.4	3333	79	64	115	64	0.9
1300	47	1.3	25	6.8	1780	58	47	84.5	41	0.35
	70	1.4	32	5.3	1853	63	51	84.5	50	0.4
	100	1.8	40	5	1763	57	47	84.5	65	0.48
	100	1.8	40	5.2	1763	56	46	83.2	65	0.47
	130	1.9	45	4.6	1874	58	47	84.5	76	0.55
	160	1.6	40	3.4	3170	74	60	115	64	0.9
1400	40	1.3	25	6.8	1742	58	47	84.5	41	0.35
	56	1.5	32	5.3	1735	61	50	84.5	50	0.4
	86	1.8	40	5	1743	57	47	84.5	65	0.48
	86	1.8	40	5.2	1743	56	46	83.2	65	0.47
	110	1.9	45	4.6	1823	58	47	84.5	76	0.55
	130	1.7	40	3.4	2961	72	58	115	64	0.9
1500	35	1.4	25	6.8	1198	56	45	84.5	41	0.35
	50	1.6	32	5.3	1636	59	48	84.5	50	0.4
	76	1.9	40	5	1656	56	45	84.5	65	0.48
	76	1.9	40	5.2	1656	55	45	83.2	65	0.47
	95	2.1	45	4.6	1692	55	45	84.5	76	0.55
	110	1.8	40	3.4	2693	70	57	115	64	0.9

UN(Vdc)	CN(μF)	ESR(mΩ)	L(nH)	Rth(K/W)	I(A)	Imax(A)-60℃	Imax(A)-85℃	Dimension φD	Dimension H	Average Weight(kg)
450	170	0.7	25	6.8	2414	92	65	84.5	41	0.35
	260	0.9	32	5.3	2240	97	65	84.5	50	0.4
	380	1	40	5	2195	95	63	84.5	65	0.48
	380	1	40	5.2	2195	93	62	83.2	65	0.47
	600	1	40	3.4	3955	100	76	115	64	0.9
600	100	0.8	25	6.8	2164	88	58	84.5	41	0.35
	150	1	32	5.3	2244	89	59	84.5	50	0.4
	220	1.1	40	5	2169	89	59	84.5	65	0.48
	220	1.1	40	5.2	2169	87	58	83.2	65	0.47
	350	1	40	3.4	3879	100	76	115	64	0.9
800	66	0.8	25	6.8	1907	91	61	84.5	41	0.35
	100	1.1	32	5.3	1998	88	59	84.5	50	0.4
	140	1.3	40	5	1843	83	55	84.5	65	0.48
	140	1.3	40	5.2	1843	82	54	83.2	65	0.47
	230	1.1	40	3.4	3404	100	73	115	64	0.9
900	47	1	25	6.8	1620	78	52	84.5	41	0.35
	70	1.2	32	5.3	1688	84	56	84.5	50	0.4
	100	1.3	40	5	1570	83	55	84.5	65	0.48
	100	1.3	40	5.2	1570	81	54	83.2	65	0.47
	160	1.2	40	3.4	2824	99	70	115	64	0.9

Reference Standard	IEC 61071, AEC Q200D
Operating Temperature	-40～105℃（hotpot）
Storage Temperature	-40～105℃
Rated Voltage	450Vdc
Rated Capacitance	1000μF
Capacitance Tolerance	±10%
Test Voltage Between T-T	675Vdc (10s, 20±5℃)
Test Voltage Between T-C	3Kvac (10s, 50Hz, 20±5℃)
tgδ	0.0002
IR×Cn	≥10,000s (20℃, 100Vdc, 1min)
Over voltage	1.1Un (30% of on-load-duration)
	1.15Un (30min/day)
	1.2Un (5min/day)
	1.3Un (1min/day)
	1.5Un (30ms per time, 1000 times during lifetime)
Max. ripple current Irms	170A (@80℃)
	200A (@80℃)
	240A (≤60s)
Î	5,000 A
Îs	15,000 A (≤30ms per time, no more than 1,000 times)
ESR	≤0.40mΩ@10kHz
Ls	≤15nH
Installation	Any direction
Failure rate	50 FIT

◆ Product Advantages
• Specifically Designed for New Energy Vehicle DC Bus: Deeply optimized for high-voltage DC bus filtering requirements in battery electric vehicles (BEV) and hybrid electric vehicles (HEV), capable of directly replacing large-capacity aluminum electrolytic capacitors with a non-polarized design that completely eliminates electrolyte leakage risk
• Extremely Low Equivalent Series Resistance (ESR): ESR values significantly lower than electrolytic capacitors result in minimal temperature rise under high-frequency ripple currents, supporting higher ripple current amplitudes and reducing inverter switching losses
• Low Equivalent Series Inductance (Ls): Non-inductive winding structure minimizes parasitic inductance, suppressing high-frequency oscillations and voltage spikes to protect power semiconductor IGBT/MOSFET devices from surge damage
• Excellent Self-Healing Performance: Metallized film self-healing characteristic handles occasional over-voltage events, consistent with high reliability requirements of automotive applications
• Plastic Case with Resin Filling: Lightweight design with vibration and weather resistance, adapting to harsh vibration and temperature environments of automotive chassis and engine compartments

◆ Key Selling Points
• Long Service Life Matching Vehicle Lifetime Requirements: Design life target exceeding 15 years/500,000 km under automotive operating conditions, far surpassing electrolytic capacitors
• AEC-Q200 Grade Quality Validation: Validated against automotive electronics reliability standards, suitable for direct adoption by OEM vehicle manufacturers
• Supports Customized Development: Capacitance, voltage, mounting dimensions, and connector interfaces can be customized according to vehicle manufacturer parameters
• Multi-Energy Adaptability: Also applicable to wind and solar power generation inverters and welding equipment inverter power supplies"

◆ Primary Applications
• DC bus filtering for main inverters in battery electric vehicles (BEV) and hybrid electric vehicles (HEV/PHEV)
• DC filtering for on-board chargers (OBC)
• Wind and solar power generation inverters
• Elevator and motor drive frequency converters
• Industrial welding equipment inverter power supplies
